Peridotite-chromitite complexes in the Eastern Desert of Egypt

Peridotite-chromitite complexes in the Eastern Desert of Egypt: Insight into Neoproterozoic sub-arc mantle processes

Mohamed Zaki Khedr a,⁎, Shoji Arai b

a Department of Geology, Faculty of Science, Kafrelsheikh University, El-Geish Street, 33516 Kafrelsheikh, Egypt

b Department of Earth Sciences, Graduate School of Natural Science and Technology, Kanazawa

University, Kakuma, Kanazawa, Ishikawa 920-1192, Japan

a b s t r a c t

The Neoproterozoic peridotite-chromitite complexes in the Central Eastern Desert of Egypt, being a part of the Arabian-Nubian Shield, are outcropped along the E–W trend from Wadi Sayfayn, Wadi Bardah, and Jabal Al- Faliq to Wadi Al-Barramiyah, from east to west. Their peridotites are completely serpentinized, and the abundance of bastite after orthopyroxene suggests harzburgite protoliths with subordinate dunites, confirmed by low contents of Al2O3, CaO and clinopyroxene (b3 vol%) in bulk peridotites. The primary olivine is Fo89.3– Fo92.6, and the residual clinopyroxene (Cpx) in serpentinites contains, on average, 1.1 wt% Al2O3, 0.7 wt% Cr2O3, and 0.2 wt% Na2O, similar in chemistry to that in Izu-Bonin-Marian forearc peridotites. The wide range

of spinel Cr-number [Cr/(Cr + Al)], 0.41–0.80, with low TiO2 (0.03 wt%), MnO (0. 3 wt%) and YFe [(Fe3+/(Cr + Al + Fe3+) = 0.03 on average)] for the investigated harzburgites-dunites is similar to spinel compositions for arc-related peridotites. The partial melting degrees of Bardah and Sayfayn harzburgites range mainly from 20 to 25% and 25 to 30% melting, respectively; this is confirmed by whole-rock chemistry and Cpx HREE modelling (~20% melting). The Barramiyah peridotite protoliths are refractory residues after a wide range of partial melting, 25–40%, where more hydrous fluids are available from the subducting slab. The Neoproterozoic mantle heterogeneity is possibly ascribed mainly to the wide variations of partial melting degrees in small-scale areas,

slab-derived inputs and primordial mantle compositions. The Sayfayn chromitites were possibly crystallized from island-arc basaltic melts, followed by crystallization of Barramiyah chromitites from boninitic melt in the late stage of subduction. The residual Cpx with a spoon-shape REE pattern is rich in both LREE and fluid-mobile elements (e.g., Pb, B, Li, Ba, Sr), but poor in HFSE (e.g., Ta, Nb, Zr, Th), similar to Cpx in supra-subduction zone (SSZ) settings, where slab-fluid metasomatism is a prevalent agent. The studied chromitites and their host peridotites represent a fragment of sub-arc mantle, and originated in an arc-related setting. The systematic increase in the volumeof chromitite podswith the increasing of their host-peridotite thickness fromNorthern to Southern

Eastern Desert suggests that the thickness of wall rocks is one factor controlling the chromitite size. The factors controlling the size of Neoproterozoic chromitite pods are the thickness, beside the composition, of the host refractory peridotites, compositions and volumes of the supplied magmas,

the amount of slab-derived fluids, and possibly the partial melting degree of the host peridotites.
